Airmax PondSeries PS10

Airmax PondSeries PS10 Aeration System

Tech Specs

	PS10
Max Pond Size	Up to 1 Acre
Max Diffuser Depth	50 Feet
Aerates Pond Up to 6-9′ Deep	Up to 1/4 Acre
Aerates Pond Up to 9-12′ Deep	Up to 1/2 Acre
Aerates Pond Over 12′ Deep	Up to 1 Acre
SilentAir Compressor	1/4 HP Rocking Piston Compressor
Running Amps	1.6 or 0.8
Voltage	115V or 230V
Wattage	184 Watts
Max CFM	2.3
Diffuser Type	(1) ProAir 4 Weighted Diffuser
Airmax Composite Cabinet	Standard Cabinet
Cabinet Dimensions	23″L x 17″W x 15″H
Power Cord	6′ Cabinet Cord 2’6″ Compressor Cord
Monthly Operating Cost (24/7)*	$13.20
ProAir Diffuser Warranty	5 Years
Compressor & Electrical Component Warranty	3 Years
Composite Cabinet Warranty	10 Years
EasySet Airline Warranty	5 Years

Easy Installation With Options

Airmax Aeration Systems are the easiest and most versatile systems to install on the market. PondSeries PS10 System can be installed at the water’s edge or up to 1/4 mile away from the pond or lake. No power is needed at the shore, and select from 115V or 230V systems. Airmax EasySet airline delivers oxygen to the water without the added expense of hiring an electrician.

Airmax Composite Cabinet

ETL electrical safety certified composite cabinet has a quiet design with a faux rock finish to blend into any landscape. The removable top and side high-density air intake filter protect the compressor and pre-wired electrical box from outside contaminants while providing easy access. Other cabinet features include an elevated base protecting against damaging flood water and a ventilation fan with a rain shroud that cools and protects against moisture and heat damage. Cabinet dimensions: 23″L x 17″W x 15″H. Comes with a 10-year warranty.

SilentAir Compressor With SmartStart Technology (IST)

The heart and soul of each PondSeries Aeration System is a powerful whisper-quiet SilentAir 1/4 HP Rocking Piston Compressor built with SmartStart Technology (IST) to protect compressor during pressurized restarts following power supply interruptions. Each highly efficient 115V or 230V compressor has rubber mounts to reduce noise and vibrations and ensure a silent operation. This compressor can push up to 2.3 CFMs of oxygen to your pond while costing as little as $0.44 daily. Comes with a 3-year warranty.

Airflow Manifold Assembly

Airmax simplifies airflow management to an individual diffuser with a single-port manifold. Optional airline quick disconnects can be added for simplified removal during maintenance or for winter storage of systems that do not run year-round. PondSeries PS10 Systems is set up for 3/8″ or 5/8″ airlines.

ProAir 4 Weighted Diffusers

Designed for maximum oxygen uptake, the ProAir 4 Weighted Diffuser incorporates high-efficiency, low-maintenance membrane sticks to release tiny oxygen bubbles into the water column. Membrane diffusers have the synergy of air stones without the headaches of cracking and acid-washing. The ProAir 4 Weighted Diffuser has an integrated check valve to prevent backpressure on the compressor. The innovative sled keeps the ProAir 4 submerged while maintaining an upright position during installation. Comes with a 5-year warranty.
